Floor plans

All twenty layouts, with the stack each one fills.

Rendered from the plan set bearing BP No. A1716-00045-2025-BP01 dated 9 February 2026. Each sheet carries its own scale bar, north point and key plan.

How to read these

The designation under each plan is the useful part.

Every sheet prints the block and the storey-and-stack range the type occupies. “Block 1, #05-04 to #31-04” means that layout is stack 04 of Block 1, from the fifth storey to the thirty-first — twenty-seven homes, all identical, differing only in height. That is what lets the whole 515 be rebuilt and checked, and it is what tells you which way a home faces before you see one.

Eight types also have a PES sheet for their first-storey home, with a private enclosed space in place of the balcony and the same total area.
